| Basic Information | |
Product series | WiFi Smart plug |
Type | Smart switch module |
Voltage | 100-250V AC 50/60Hz |
Max.Load | 16A/4000W |
Use method | Plug and play |
MCU | BK7132t |
Certification | CE/ROHS |
Standby power consumption | 0.5W/Hour |
| Appearance | |
Color | white |
Dimension | 82mm*82mm*75mm |
Net weight | 126.4g |
Gross weight | 126.5g |
Packing specification | 80 PCS |
Packing size | 350mm*350mm*360mm |
Net weight | 9kg |
Gross weight | 11kg |
Casing material |
PC+ABS PC+ABS |
| Features | |
Functions | Remote control, smart timing/delay/countdown, status feedback, power-off memory, voice control, sharing function, smart scene control, manual switch |
voice control | Alexa、Google Assistant、SmartThings、DuSmart Speaker、TmallGenie |
Operating systems | Android & ios |
| Wirelessstandard | |
| Wi-Fi | IEEE802.11b/g/n 2.4GHz(2400M-2483.5M) |
Antenna | PCB board with antenna |
Security mode | WPA/WPA2 |
Encryption type | WEP/TKIP/AES |
| Working Enviroment | |
Applicable place | Indoor |
Working temperature | -20°C - 50°C |
Working humidity | 5%-95% RH，non-condensing |
Working height | Less than 2000m |
Sales Hotline：0755-81465479
| Basic Information | |
Product series | WiFi Smart plug |
Type | Smart switch module |
Voltage | 100-240V AC 50/60Hz |
Max.Load | 10A/2400W |
Use method | Plug and play |
MCU | BK7132t |
Certification | CE/ROHS |
Standby power consumption | 0.5W/Hour |
| Appearance | |
Color | white |
Dimension | 116mm*66mm*86mm |
Net weight | 170g |
Gross weight | 171g |
Packing specification | 60 PCS |
Packing size | 400mm*300mm*300mm |
Net weight | 10kg |
Gross weight | 12kg |
Casing material |
PC+ABS PC+ABS |
| Features | |
Functions | Remote control, smart timing/delay/countdown, status feedback, power-off memory, voice control, sharing function, smart scene control, manual switch, power statistics (can count: current, voltage, power, power consumption) |
voice control | Alexa、Google Assistant、SmartThings、DuSmart Speaker、TmallGenie |
Operating systems | Android & ios |
| Wirelessstandard | |
| Wi-Fi | IEEE802.11b/g/n 2.4GHz(2400M-2483.5M) |
Antenna | PCB board with antenna |
Security mode | WPA/WPA2 |
Encryption type | WEP/TKIP/AES |
| Working Enviroment | |
Applicable place | Indoor |
Working temperature | -20°C - 50°C |
Working humidity |
5%-95% RH， 5%-95% RH，non-condensing |
Working height | Less than 2000m |
